Takstar MX630 Webcast Pro Sound Card

34 People watching this product now!

General

  • Professional USB sound card for live streaming, podcasting, recording, and karaoke
  • Compatible with Windows 7, 8, and 10
  • USB 2.0 high-speed data transmission with ultra-low latency
  • Supports 24-bit/96kHz high-resolution audio
  • ASIO 2.0 driver support for professional recording software and VST plugins
  • Supports MME, WDM, and DirectSound audio standards

Audio Inputs & Outputs

  • 2 × XLR + 6.35mm combo microphone/instrument inputs
  • 2 × 6.35mm headphone outputs
  • 2 × 6.35mm balanced left/right speaker outputs
  • 1 × 3.5mm smartphone connection for dual-device live streaming
  • 1 × 3.5mm accompaniment input

Microphone Performance

  • Frequency Response: 20Hz–20kHz
  • Adjustable Gain: Over 50dB
  • Gain Range: +54dB
  • Low distortion for clean vocal recording

Headphone Output

  • Frequency Response: 20Hz–20kHz
  • Dynamic Range: 99dB
  • Signal-to-Noise Ratio: 103dB
  • Output Power: 90mW/100Ω
  • Supports headphones from 32Ω to 600Ω

Line Output

  • Frequency Response: 20Hz–20kHz
  • Dynamic Range: 98dB
  • Signal-to-Noise Ratio: 102dB
  • Maximum Output Level: +0dBV

Power & Build

  • Power Supply: DC 12V / 1A
  • Operating Temperature: 0°C–40°C
  • Dimensions: 140 × 140 × 33.5mm
  • Weight: Approximately 465g

Package Includes

  • MX630 Webcast Pro Sound Card
  • USB Type-C Data Cable
  • 2 × Audio Cables
  • Power Adapter
  • User Manual

Packaging

  • Color Box
  • Box Size: 275 × 177 × 78mm
Products Description

The MX630 Webcast Pro Sound Card is a professional USB audio interface designed for live streaming, online karaoke, podcasting, music recording, voice chats, and content creation. It works smoothly with Windows 7, 8, and 10 and uses a USB 2.0 connection for fast data transfer with ultra-low latency, ensuring real-time audio performance.

It supports high-quality 24-bit/96kHz audio recording and playback, delivering clear, detailed, and natural sound for both vocals and instruments. Equipped with ASIO 2.0 drivers, the MX630 is compatible with multiple VST plugins, making it ideal for professional music production and live broadcasting.

It features two XLR/6.35mm combo inputs for connecting microphones or musical instruments, dual headphone outputs, balanced speaker outputs, and a dedicated 3.5mm smartphone port that allows simultaneous streaming on both a PC and mobile device. Independent volume controls for microphones, headphones, speakers, and smartphone recording provide complete control over your audio setup.

With low distortion, excellent signal quality, wide frequency response, external DC power support, and a compact, durable design, the MX630 is a reliable solution for streamers, musicians, podcasters, karaoke enthusiasts, and home recording studios.
